Polaris Sportsman 500 Poly Plow Blade Complete Snow Plow System by Moose

Stop shoveling your driveway or struggling with a heavy steel plow that rusts and sticks to the snow. The Moose Poly Plow Blade Complete System turns your Polaris Sportsman 500 into the ultimate winter workhorse. It features a slick, high-density polyethylene blade that lets wet, heavy snow slide right off, meaning you clear your property faster with less strain on your ATV. It comes as a complete, bolt-on kit engineered and made in the USA. Don't dread the next blizzard—conquer it from the comfort of your ATV seat.

Kit includes:
- (1) Poly Plow Blade
- (1) Push Tube System
- (1) Machine-specific Plow Mount
(Note: A winch is required for lifting/lowering and must be purchased separately if your ATV is not already equipped with one).

Poly Plow Blade:

- Blade Material: 1/8" thick high-density polyethylene (UHMW) supported by a high-strength steel rib framework.
- Swivel Positions: 5 adjustable blade angles via a heavy-duty 3/8" steel open swivel.
- Attaching Points: 20-inch wide dual blade mounting points for maximum structural stability.
- Hardware Included: Heavy-duty adjustable skid shoes and a flexible plow flap
- Available Blade Widths:

• • 60-Inch Blade (4501-0910), Black
  • 72-Inch Blade (4501-0911), Black

Heavy-Duty Push Tube (4501-0759):

- Attachment Point: Center chassis/belly of your Polaris Sportsman.
- Best For: Heavy-duty commercial plowing or clearing packed ice.
- Key Advantage: Distributes impact forces evenly across the entire center frame of the quad to prevent front-end stress.
- Connection Method: Traditional mid-mount pin setup under the machine.
- Required Component: Must be paired with a vehicle-specific Moose Standard Bottom Mount Plate.

Plow Mount (4501-0613):

- Quick-connect mounting hardware allows easy hookup and fast removal
- Universal, heavy-duty push tube withstands the roughest use
- Blade swivel constructed of 3/8" steel with 20" blade attaching points for greater blade support and strength
- Open swivel eliminates dirt and snow buildup in the pivot point
- Five blade swivel positions and four-way blade pitch adjustment
- Plow bottom-mount kit includes all necessary hardware to attach universal push tube and plow
- Made in the USA
**Image is only a representation of our ATV Bottom-Mount Kit, actual product may vary depending on vehicle fitment**

*****OPTIONAL ADD-ONS*****

• Electric Turn Kit (4501-0946)
  - Works on all Moose push tubes and straight blade plows
  - Direct bolt-on installation
  - Easy thumb-switch operation and wiring harness included
  - Requires a winch for raising and lowering the plow
  - Precision-cut ring and pinion gear system for positive mesh
  - Very quick right to left operation
  - Heavy duty 12V electric motor
  - Fully welded for world-class strength, durability and longevity
  - Engineered and final assembled in the USA

• Winch (Aggro)
  - Black Powdercoated Finish
  - IP67 Waterproof Sealing
  - Durable Planetary Gear Train
  - 50-foot line with a 3/16-inch diameter
  - Includes Handlebar-Mounted Rocker Switch, Zinc-Plated Hook, Contactor, Power Cables, Mounting Plate and Hardware

• • • Wire Rope Models: Includes Roller Fairlead
      • (4505-0759) 2500 lb Load Capacity
      • (4505-0761) 3500 lb Load Capacity
      • (4505-0763) 4500 lb Load Capacity
    • Synthetic Rope Models: Includes Hawse Fairlead
      • (4505-0760) 2500 lb Load Capacity
      • (4505-0762) 3500 lb Load Capacity
      • (4505-0764) 4500 lb Load Capacity

• Winch Mount (4505-0913)
  - Quick-connect mounting hardware allows easy hookup and fast removal
  - Winch mount kit accepts WARN, Moose, and Superwinch winches
  - Made in the USA

  ** Actual Winch Mount may look different than reference photo shown **

• Plow Markers (4501-0835)
  - A pair of 16-inch high-visibility yellow plow markers designed to attach directly to the outer edges of your snow plow blade

• Plow Side Shields
  - Attaches to the forward end of an angled plow blade to greatly reduce the amount of overflowing snow or dirt
  - Put plow side shields on both ends of a straight blade to contain even more plowed material
  - Easy to install on either side of a plow blade (works only on smaller side of County Plows)
  - Some drilling is required
  - Made in the U.S.A.

  • • (4501-0775): Left Side Only

    • (4501-0774): Right Side Only

    • (4501-0774/4501-0775): Both sides; Left & Right.

Stop Shoveling. Start Riding.

Whether you are clearing a massive residential driveway or managing a commercial lot, the Moose Poly Plow System turns hours of back-breaking labor into minutes of fun. It is tough, fast, and engineered to fit your Polaris Sportsman 500 flawlessly. Get yours today and make light work of the heaviest winters!
